FRAME
A1 premium butted alloy, zero-stack head tube, internal cable routing, 135x9mm forged dropouts, chainstay-mounted disc brake, replaceable alloy derailleur hanger, stealth rack mounts, dropper post compatible
FORK
SR Suntour XCM 27.5, 30mm Stanchions, Rx Tune, coil spring, custom Multi-Circuit damping w/lockout, QR, 80/90/100mm travel (size-specific), 42mm offset
FRONT HUB
Shimano HB-TX505, Center Lock™ disc, 9x100mm spacing, quick-release, 28h
REAR HUB
Shimano FH-TX505, Center Lock™ disc, 9x135mm spacing, quick-release, 32h
RIMS
Stout Alloy, hookless, pinned, disc only, double-wall, 25mm inner width, 28h
INNER TUBES
Presta, 40mm valve
FRONT TIRE
Ground Control Sport, 27.5x2.3"
REAR TIRE
Ground Control Sport, 27.5x2.3"
CRANKSET
Stout 1x, forged alloy
BOTTOM BRACKET
Square-tapered, 73mm, internal bearings, 122.5mm spindle
SHIFT LEVERS
microSHIFT Advent, 9-speed
REAR DERAILLEUR
microSHIFT Advent, 1x9 w/ clutch
CASSETTE
microSHIFT Advent, 9-speed, 11-42t
CHAIN
KMC X9EPT, 9-speed, anti-corrosion coating w/ reusable Missing Link™
FRONT BRAKE
Shimano BR-MT200, hydraulic disc, 180mm
REAR BRAKE
Shimano BR-MT200, hydraulic disc, 160mm
HANDLEBARS
Stout Mini Rise, alloy, 9-degree backsweep, 15mm rise, 31.8mm
GRIPS
Specialized Trail Grips, lock-on
STEM
Stout 3D-forged alloy, 31.8mm, 6-degree rise
SADDLE
Bridge Sport, Steel rails, 155/143mm
SEATPOST
Alloy, 12mm offset, 2-bolt clamp, 30.9mm
SEAT BINDER
Alloy, quick release, 34.9
